关于.net：如何在代码中定义列表视图模板

2023-04-17 03:46:00

How to define listview templates in code

我正在编写一个Composite控件，其中包含一个用于显示项目表的列表视图。通常，在Asp.NET中使用ListView时，我会在代码转发中定义模板。

1
2
3
4
5
6
7
8
9
10
11

我认为是这样的：

1
2
3
4
5
6
7

ListView view = new ListView();
view.LayoutTemplate = .....
view.ItemTemplate = .....

// when do I call these?
view.DataSource = myDataSource;
view.DataBind();

更新：
我通过实现ITemplate接口创建了2个模板：

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21

private class LayoutTemplate : ITemplate
{
public void InstantiateIn(Control container)
{
var outer = new HtmlGenericControl("div");
var inner = new HtmlGenericControl("div") { ID ="itemPlaceholder" };
table.Rows.Add(row);

container.Controls.Add(table);
}
}

private class ItemTemplate : ITemplate
{
public void InstantiateIn(Control container)
{
var inner = new HtmlGenericControl("div");

container.Controls.Add(inner);
}
}

我可以使用添加它们：

1 2	dataList.LayoutTemplate = new LayoutTemplate(); dataList.ItemTemplate = new ItemTemplate();

但是然后我被卡住了，因为container.DataItem为null。

诀窍是在ItemTemplate中订阅itemplaceholder的数据绑定事件。

完整的解决方案：

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72

public class FibonacciControl : CompositeControl
{
public FibonacciControl()
{
// ....
}

protected override void CreateChildControls()
{
base.CreateChildControls();

ListView view = new ListView();

view.LayoutTemplate = new LayoutTemplate();
view.ItemTemplate = new ItemTemplate();

view.DataSource = FibonacciSequence();
view.DataBind();

this.Controls.Add(view);
}

private IEnumerable<int> FibonacciSequence()
{

int i1 = 0;
int i2 = 1;

for (int i = 0; i < Iterations; i++)
{
yield return i1 + i2;
int temp = i1 + i2;
i1 = i2;
i2 = temp;
}
yield break;
}

public int Iterations { get; set; }

private class LayoutTemplate : ITemplate
{

public void InstantiateIn(Control container)
{
var ol = new HtmlGenericControl("ol");
var li = new HtmlGenericControl("li") { ID ="itemPlaceholder" };
ol.Controls.Add(li);

container.Controls.Add(ol);
}
}

private class ItemTemplate : ITemplate
{
public void InstantiateIn(Control container)
{
var li = new HtmlGenericControl("li");

li.DataBinding += DataBinding;
container.Controls.Add(li);
}

public void DataBinding(object sender, EventArgs e)
{
var container = (HtmlGenericControl)sender;
var dataItem = ((ListViewDataItem)container.NamingContainer).DataItem;

container.Controls.Add( new Literal(){Text = dataItem.ToString() });
}
}
}

此链接可能会有帮助吗？以编程方式使用模板控件

在设计时生成模板(以便将其保存在aspx文件中)有点棘手，但是DataBinding将自动工作。

这是一个基于Sonteks示例的示例，该示例创建一个模板，该模板包含随后使用数据绑定绑定的元素。

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138

public partial class View : PortalModuleBase
{
protected void Page_Load(object sender, EventArgs e)
{

}

#region MasterListView_ItemDataBound
public void MasterListView_ItemDataBound(object sender, ListViewItemEventArgs e)
{
ListViewItem objListViewItem = (ListViewItem)e.Item;
ListViewDataItem objListViewDataItem = objListViewItem as ListViewDataItem;

if (objListViewDataItem != null)
{
Tab objTab = (Tab)objListViewDataItem.DataItem;
IEnumerable<Tab> Tabs = CustomData(objTab.TabID);

Label TabIDLabel = (Label)objListViewItem.FindControl("TabIDLabel");
Label TabNameLabel = (Label)objListViewItem.FindControl("TabNameLabel");

TabIDLabel.Text = objTab.TabID.ToString();
TabNameLabel.Text = objTab.TabName;

AddListView(objTab.TabName, objListViewItem, Tabs);
}
}
#endregion

#region CustomData
static IEnumerable<Tab> CustomData(int? ParentID)
{
TabAdminDataContext objTabAdminDataContext = new TabAdminDataContext();

var myCustomData = from Tabs in objTabAdminDataContext.Tabs
where Tabs.ParentId == ParentID
select Tabs;

return myCustomData.AsEnumerable();
}
#endregion

#region AddListView
private void AddListView(string CurrentTabName, Control container, IEnumerable<Tab> ChildTabs)
{
// The Tab has Children so add a ListView
if (ChildTabs.Count() > 0)
{
ListView ChildListView = new ListView();
ChildListView.ID ="ChildListView";
ChildListView.ItemCommand += ListView_ItemCommand;
ChildListView.EnableViewState = true;
ChildListView.LayoutTemplate = new MyLayoutTemplate();
ChildListView.ItemTemplate = new MyItemTemplate();
ChildListView.DataSource = ChildTabs;
ChildListView.DataBind();

// Put the ListView in a Panel
var oTR = new HtmlGenericControl("tr") { ID ="ChildListViewTR" };
var oTD = new HtmlGenericControl("td") { ID ="ChildListViewTD" };

Panel objPanel = new Panel();
objPanel.ID ="ListViewPanel";
objPanel.ToolTip = CurrentTabName;
objPanel.Controls.Add(ChildListView);

oTD.Controls.Add(objPanel);
oTR.Controls.Add(oTD);
container.Controls.Add(oTR);
}
}
#endregion

#region ListView_ItemCommand
protected void ListView_ItemCommand(object sender, ListViewCommandEventArgs e)
{
LinkButton objButton = (LinkButton)sender;
Label1.Text = objButton.Text;
MasterListView.DataBind();
}
#endregion

#region MyLayoutTemplate
public class MyLayoutTemplate : ITemplate
{
public void InstantiateIn(Control container)
{
var oTR = new HtmlGenericControl("tr") { ID ="itemPlaceholder" };
container.Controls.Add(oTR);
}
}
#endregion

#region ItemTemplate
public class MyItemTemplate : ITemplate
{
public void InstantiateIn(Control container)
{
var oTR = new HtmlGenericControl("tr");

var oTD1 = new HtmlGenericControl("td");
LinkButton TabIDLinkButton = new LinkButton();
TabIDLinkButton.ID ="TabIDLinkButton";
oTD1.Controls.Add(TabIDLinkButton);
oTR.Controls.Add(oTD1);

var oTD2 = new HtmlGenericControl("td");
Label TabNameLabel = new Label();
TabNameLabel.ID ="TabNameLabel";
oTD2.Controls.Add(TabNameLabel);
oTR.Controls.Add(oTD2);

oTR.DataBinding += DataBinding;
container.Controls.Add(oTR);
}

public void DataBinding(object sender, EventArgs e)
{
var container = (HtmlGenericControl)sender;
var dataItem = ((ListViewDataItem)container.NamingContainer).DataItem;
Tab objTab = (Tab)dataItem;

LinkButton TabIDLinkButton = (LinkButton)container.FindControl("TabIDLinkButton");
Label TabNameLabel = (Label)container.FindControl("TabNameLabel");

TabIDLinkButton.Text ="+" + objTab.TabID.ToString();
TabNameLabel.Text = objTab.TabName;

IEnumerable<Tab> ChildTabs = View.CustomData(objTab.TabID);

View objView = new View();
objView.AddListView(objTab.TabName, container, ChildTabs);
}

}
#endregion

}

设置一个类似的类：

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16

public delegate void InstantiateTemplateDelegate(Control container);

public class GenericTemplateImplementation : ITemplate
{
private InstantiateTemplateDelegate instantiateTemplate;

public void InstantiateIn(Control container)
{
this.instantiateTemplate(container);
}

public GenericTemplateImplementation(InstantiateTemplateDelegate instantiateTemplate)
{
this.instantiateTemplate = instantiateTemplate;
}
}

然后执行以下操作：

1
2
3
4

view.LayoutTemplate = new GenericTemplateImplementation(p =>
{
p.Controls.Add(new Label { Text ="Foo" });
});
